NICE - MIRIAM - CRISTAL - PRETTY - DIANA - KRISS - MARY
EN
POS.
REFERENCE
DESCRIPTION
3
SELECT
LANGUAGE
Press once P3 key and with P1 and P2 keys select the desired language.
4
STAND-BY MODE
It activates a function which, if the set ambient temperature has been exceeded for
more then 10 minutes, start the switching off phase up. If the ambient temperature
has fall at more than 2°C, the stove will restart automatically up, starting from
START
UP a pag. 67
. Press once P3 key and with P1 and P2 keys put in “OFF” or “ON”.
CAUTION: do not activate if CHRONO function is active!
5
BUZZER (audio
alarm)
Press once P3 key and with P1 and P2 keys put in “OFF” or “ON”.
6
INITIAL LOADING
When the stove has its first ignition, the auger is completely empty. If it should be
necessary do a precharge by pressing P3 key, then P1 key for starting up and P4 key
for stop.
7
STOVE STATE
It shows all parameters connected to the stove state: this is a menu for the Authorized
Techinician
8
TECHNICA
SETTING
Only for the Authorized Technician.
9
SET FLAME
It enables to set the flame dipending on the draught of the chimney flue.
10.5
START UP
We remind you that the first ignition must be carried out by a specialized and authorixed technician who
will check that all is installed in compliance with current regulations and checks the efficiency.
• If inside the combustion chamber there are booklets, manuals, etc..., remove them.
• Check if the door is correctly closed.
• Check if the stove is correctly inserted in the electric socket.
• Before switching the stove on, assure you the burning pot is clean.
• To start the stove up, keep pressed P4 key for an instant till it will be shown “START” and “PREHEATING
WAIT”: the preheating of the ingnition resistance starts. After 2 minutes about, it will be shown “PELLET
LOAD, FIRE WAIT”, in this phase the auger loads the pellet and the heating of the resistance continues.
When the temperature is sufficiently high (after 7-10 minutes about), the ignition is considered as
happened and on the display shows “FIRE PRESENT”.
• Completed the phase “FIRE PRESENT”, the control unit enter the “WORK” phase showing the set calorific
power and ambient temperature. It is in this phase that P5 and P6 keys settle the stove power from 1 to
5. If the value of the ambient temperature exceeds the limit set on the keyboard on the temperature
setting, the calorific power will be carried at theminimum showing “WROK MODULA”. When the ambient
temperature turns back below the set temperatur, the stove turns back to the set power.
10.6
STOVE ADJUSTMENT
The stove is adjusted according to the chimney flue and used pellets datas, as per technical characteristics
(see
FEATURES a pag. 87
). If the datas do not correspond, the authorized technician can adjust the stove.
• If the pellet is small in size and with a greater calorific power, (for example: encrusted burning pot),
the pellet drop must be decreased from the menu “SET FLAME”, press P3 “PELLET TYPE”, press P3 again
“PELLET LOADING” and with P2 key decrease the pellet quantity from -1 (which is -2%) till -9 (which is
-18%).
• If the chimney flue has a lower draught (for example: weak flame, sooty glass) the revolutions of the
geared motor must be increased from the menu “SET FLAME”, press P5 “CHIMNEY TYPE”, press P3 “FUME-
FAN” and with P1 key increase the fume fan revolutions from +1 (which is +5%) till +9 (which is +30%).
• If the chimney flue has a greater draught (for example: because of pellets fall on the burning pot)
decrease the fume fan revolutions from -1 to -9.
Pay attention if the value is positive or negative..
