12.4
FUME CHAMBER CLEANING
Every 4/8 weeks the fume chamber cleaning must be executed.
Fig. 32 - Fume chamber
Fig. 33 - Pulizia camera fumi
• Unscrew the 2 fume chamber closing zincate panel screw which stands on the back of the stove (see
Fig. 32 a pag. 75
).
• Clean with a vacuum cleaner the ash which has accumulated on the inner (see
Fig. 33 a pag. 75
).
• After the cleaning the opposite operation is to repeat checking the gasket efficiency and integrity: if
necessary provide for its replacement by an Authorized Technician.
12.5
FUME CONDUIT CLEANING
The exhaust system must be cleaned every month.
Fig. 34 - Fume conduit cleaning
• Remove the inspection lid of the T-union (see
Fig. 34 a pag. 75
).
• Extract the ash which has accumulated in the inner.
• After the cleaning repeate the opposite operation checking the integrity and eficiency of the gasket: if
necessary have it replaced by an Autorized Technician.
It is important to sealed the cap othrwise noxiuous fumes will propagate among the
room.
