of conformity of the system and will assume the whole responsibility on the final installation and on the
resulting good running of the product.
• As equipment with the stove there is a testing and maintenance manual which must be periodically
executed by the installer.
• Check if there is the combustible air inlet.
• Check the probable presence of other stoves or appliances which could depress the room (see
EXTERNAL AIR INLET a pag. 56
).
• Check at switched on stove if there is the presence of CO in the room.
• Check if the chimney has the necessary draught.
• Check if during the fume passage all has been executed in safety (probable fume losses and distances
from flammable materials, etc.…).
• The installation of the appliance must enable an easy access for appliance, fume exhaust pipes and
chimney flue cleaning.
• The installation must enable en easy access to the electric connection plug (see
ELECTRIC CONNECTION
a pag. 63
).
• It is forbidden to install the stove in bedrooms, bathrooms and in rooms used for storing combustible
materials and in one-room flats.
• The installation in one-room flats is allowed if they are in sealed chamber.
• In any case the stove must not be installed in rooms where it can get in touch with water or water
splashes because this can cause burn hazards and short-circuit.
• To install more appliances, the external air inlet must be correctly dimensioned (see
EXTERNAL AIR INLET
a pag. 56
).
9.2
OVERALL DIMENSIONS
Fig. 12 - General dimensions
LEGEND Fig. 12 a pag. 60
1
48,6 - 55 -57 cm
2
95 cm
3
46,6 - 47 cm
4
26,5 cm
5
17 cm
6
13,2 cm
