7.2
CHIMNEY FLUE
Fig. 2 - Chimney Flues
LEGEND Fig. 2 a pag. 52
1
Chimney flue with insulated stainless-steel
pipes
2
Chimney flue on the existing chimney
3
Inspection plug
4
Inspection door
5
≥ 3,5 mt
• The chimney flue or chimney is of great importance for the correct running of the heating appliance.
• It is fundamental that the chimney flue is perfectly built and always maintained with a perfect efficiency.
• The chimney flue must be sole (see
Fig. 2 a pag. 52
) with insulated stainless-steel pipes (1) or installed
on the existing chimney flue (2).
• Both this solutions must be endowed with an inspection plug (3) and/or an inspection door (4).
It is forbidden to connect more pellet stoves or any other heating appliance to the
same chimney flue.
