NICE - MIRIAM - CRISTAL - PRETTY - DIANA - KRISS - MARY
EN
DESCRIPTION
PRETTY 8,5 kW DIANA 8,5 kW KRISS 8,5 kW MARY 8,5 kW
WIDTH
51,5 cm
55,0 cm
57,0 cm
51,8 cm
DEPTH
46,5 cm
46,5 cm
47,0 cm
46,5 cm
HEIGHT
94,5 cm
95,0 cm
95,0 cm
99,5 cm
WEIGHT
78-86 kg
78,5-82-104 kg 80-94 kg
75 kg
INTRODUCED THERMIC POWER
(Min/Max)
4,4 - 9,7 kW 4,4 - 9,7 kW 4,4 - 9,7 kW 4,4 - 9,7 kW
NOMINAL THERMIC POWER
(Min/Max)
4,1 - 8,5 kW 4,1 - 8,5 kW 4,1 - 8,5 kW 4,1 - 8,5 kW
EFICIENCY (Min/Max)
92- 88 %
92- 88 %
92- 88 %
92- 88 %
FUME TEMPERATURE (Min/Max)
117 - 208 °C 117 - 208 °C 117 - 208 °C 117 - 208 °C
FUME MAXIMUM LOADING CAPACITY
(Min/Max)
4,08 - 6,6 g/s
4,08 - 6,6 g/s
4,08 - 6,6 g/s
4,08 - 6,6 g/s
CO EMISSIONS (13% O
2
) (Min/Max)
0,034 - 0,019 % 0,034 - 0,019 % 0,034 - 0,019 % 0,034 - 0,019 %
CO
2
EMISSIONS (Min/Max)
7,5 - 10,4 %
7,5 - 10,4 %
7,5 - 10,4 %
7,5 - 10,4 %
Medium CO CONTENTS at 13% O
2
(Min/Max)
430 - 236 mg/Nm
3
430 - 236 mg/Nm
3
430 - 236 mg/Nm
3
430 - 236 mg/Nm
3
Medium POWDER CONTENTS at 13%
O
2
(Max)
29 mg/Nm
3
29 mg/Nm
3
29 mg/Nm
3
29 mg/Nm
3
CHIMNEY DEPRESSION (Min/Max)
10 - 11 Pa
10 - 11 Pa
10 - 11 Pa
10 - 11 Pa
MINIMUM SAFETY DISTANCE from
flammable materials
30 cm
30 cm
30 cm
30 cm
ON SHARED CHIMNEY FLUE
NO
NO
NO
NO
FUME OUTLET DIAMETER
Ø80 mm
Ø80 mm
Ø80 mm
Ø80 mm
COMBUSTIBLE
Pellet Ø6-7 mm Pellet Ø6-7 mm Pellet Ø6-7 mm Pellet Ø6-7 mm
PELLETS HEATING VALUE
5 kWh/kg
5 kWh/kg
5 kWh/kg
5 kWh/kg
PELLETS HUMIDITY
≤ 10%
≤ 10%
≤ 10%
≤ 10%
HEATING VOLUME 18/20°C Coeff.
0,045 kW (Min/Max)
98 - 205 m
3
98 - 205 m
3
98 - 205 m
3
98 - 205 m
3
HOURLY CONSUMPTION (Min/Max)
0,91 - 2,01 kg/h 0,91 - 2,01 kg/h 0,91 - 2,01 kg/h 0,91 - 2,01 kg/h
HOPPER CAPACITY
18 kg
18 kg
18 kg
18 kg
RANGE (Min/Max)
9,0 - 19,8 h
9,0 - 19,8 h
9,0 - 19,8 h
9,0 - 19,8 h
SUPPLY
230 V - 50 Hz
230 V - 50 Hz
230 V - 50 Hz
230 V - 50 Hz
POWER INPUT (Max)
360 W
360 W
360 W
360 W
INGNITER RESISTANCE POWER INPUT 300 W
300 W
300 W
300 W
MINIMUM EXTERNAL AIR INLET (last
effective area)
80 cm
2
80 cm
2
80 cm
2
80 cm
2
STOVE WITH SEALED CHAMBER
NO
NO
NO
NO
EXTERNAL AIR INLET FOR SEALED
CHAMBER
-
-
-
-
